Beam Member Check in Ansys with SDC Verifier according to Eurocode 3. Structural Fire Design.

We made a video tutorial to show how easy you can perform Beam Member Check in Ansys according to Eurocode 3. Structural Fire Design with the help of SDC Verifier.

• 00:00 Introduction
• 00:27 Opening model (Lattice structure)
• 01:15 Adding EC 3 Fire Design Standard to SDC Verifier project
• 01:58 Input data to be set up by user
• 07:57 Overview of the property checks
• 10:17 Classification
• 10:47 Axial Check
• 12:35 Buckling compression Check
• 13:43 Bending Check
• 14:20 Lateral torsional buckling Check
• 14:50 Shear Check
• 15:13 Combined compression and bending Check
• 16:01 Resistance Overall Check
• 17:18 Brief overview on a Calculation
• 19:53 Outcomes of the Axial Check
• 22:34 Outcomes of the Buckling compression Check
• 24:22 Outcomes of the Bending Check
• 25:37 Outcomes of the Lateral torsional buckling Check
• 27:10 Outcomes of the Shear Check
• 28:40 Outcomes of the Compression and bending Check
• 30:19 Outcomes of the Resistance Overall Check
• 33:21 The influence of the temperature on the structure
