Norsok N004 (Rev. 3, 2013)

The Norsok N004 (Rev. 3, 2013) standard in SDC Verifier provides full verification of tubular member strength and joint stability for offshore steel structures. Based on the Norwegian shelf guidelines, the standard is ideal for fixed platforms, jackets, and braced tubular structures under offshore loading.

Scope of Application:

• Tubular members with thickness ≥ 6 mm, D/t < 120, Yield < 500 MPa
• Member and joint-level checks (K, TY, X-type)
• Combination with AISC 360-10 or Eurocode 3 for non-tubular elements

Key Features:

• Automatic beam and joint recognition via Beam and Joints Finder
• Axial, bending, and gap-dependent joint capacity calculations
• Full overlapping joint evaluation, including shear UC and modified force/moment UC
• Chord/brace force interpolation and Q-factors as per NORSOK
• Validation for particular cases when model geometry introduces recognition edge cases

Highlights for Engineers:

• Define custom safety factors or use values per Section 6.3.7
• Configure joint properties manually or use Find Connections and Preview tools
• Support for can joints, effective length settings, and interaction equations
• Fully compliant with ISO 19900 design principles and NS 3472 / EN 1993-1-1 references

Engineers can perform both Member Checks and Joint Checks across the model. Detailed reports include UC plots, gap values, stress ratios, and brace type classifications.
